XM200G Workflow for Dental Applications

Build Set-Up

Materialise Magics for Dental Pre-print module automatically fixes, orients and labels parts.
Software automatically adds e-stage supports which are specifically designed to reduce powder use.

Loading Printer

Simply fill build chamber with the certified dental powder of choice.
We offer two certified dental powders from BEGO Medical: MEDILOY ® S-CO and WIRONIUM® RP. Click for more.

Printing

Upload and run your print, via ethernet or USB, utilizing exposure parameters designed by Xact Metal specific for certified BEGO Medical dental powders.
Print time varies depending on XM200G laser/wattage configuration. Click to learn more about XM200G options.

Plate Removal

Build plate with finished print can be easily removed from the machine by unscrewing each corner.
Completed print is fully dense (99.5% +) when removed from machine.

Heat Treating

Parts are heat treated to minimize residual stresses and reduce risk of dimensional changes upon part removal.
*Xact Metal does not manufacture or sell commercial furnaces, but is able to provide recommendations upon request.

Parts Removal

Parts can be removed from plate using a bandsaw. Supports make part removal simple while reducing potential part damage.
Smaller components may be removed by hand.

Hand Finishing

Manually remove small or internal supports with pliers and common hand tools.
Automatically generated E-Stage supports are designed for quick and easy removal.

Polishing

Industry standard polishing processes can be used to finish the part.
Processes may include light abrasive finishing, media blasting, or electro-polishing.

The capabilities of the XM200G make it well-suited for dental applications, which typically require a fast printing speed, quick job turnover, a high-quality surface finish, and the ability to print very fine components. Designed for easy integration into a facility, the XM200G fits through a standard doorway and requires minimal operation training.
